Pipeline and Construction Equipment and Support

Challenger Services is a global company that supplies construction and pipeline equipment and support items.



Address
4530 South Jackson Avenue,
Tulsa, Oklahoma,
74107,
United States of America
Phone
Fax Number
Share

Challenger Services is a global company that supplies construction and pipeline equipment and support items. Challenger aims to offer top-quality equipment that makes pipeline construction easier, safer and more economical for contractors. Challenger equipment such as cranes, pipelayers and earthmovers is used for applications in construction, rental fleet, shipbuilding, railroad, vehicle manufacturing and repair.

Challenger welder tractors are modifications and additions to existing designs, gleaned from over 55 years of experience in the industry. Along with tractors, Challenger also offers heavy-duty designed fill pumps, test pumps, combination pumps and ditch pumps. Challenger support items include welding machines, holiday detectors, slings, spreader bars, external clamps and accessories.

Challenger also handles sales and services for vehicles and machines built by a wide range of global brands. This includes Caterpillar, Grove, Sabre International, Wheatley, Peerless, Goulds and Quincy. Challenger offers complete product support for all models of welder tractors, pumps and other products, irrespective of manufacturer.

Hydraulic pipelayers

Challenger hydraulic pipelayer attachments are easy to operate and require minimum training. Hydraulics require less maintenance than mechanically operated drawworks, resulting in cost savings. The attachments are available with various Caterpillar, Komatsu and Dressta tractors. Lifting capacity ranges from 10,000lbs to 200,000lbs. Challenger can mount the attachments itself or ship them around the world for installation.

The Challenger Services CP66 pipelayer is available with a Cat® D6D LGP or D6D tractor.
The D7G Auto 400 welder tractor is equipped with four Lincoln Idealarc DC-400 rectifier welders.
Challenger external segmented lineup clamps are suitable for pipe diameters 52in and above.
The Challenger CPT-45 pipe trailer has a 90,000lb net payload capacity that can be used for pipes or general cargo.
The Challenger Vaculift RC12 pipe lifter can handle single or double-jointed pipe from 10cm to unlimited size diameter.
Pipe-handling Challenger roli cradles provide even support for heavy wall pipe to prevent 'egging'.
The Challenger Test Pump Model T-31 has a performance of up to 165 gallons per minute at 2,950 PSI with a 2.5in plunger.
Challenger pipe bending sets are available for use with all Challenger pipe bending machines for pipe diameters up to 60in.

Welder tractors

Challenger welder tractors offer versatility, solid state circuitry and avoid surging during the welding process. They use Lincoln Idealarc DC-400 rectifier welders with the D6E Auto 400 tractor also offering the option for Miller XMT 350 welders. Both welders are low maintenance with a long service life, easy operation and great arc performance. Challenger stocks these models separately and will also repair welders.

Challenger Auto Pac welder packages are mostly bolt on for simple onsite installation. The attachments are available for a variety of tractor brands including Caterpillar, Dressta and Komatsu. They can be shipped in containers or crated as break-bulk cargo.

Challenger also offers combination welder and pipelayer and welder and loader tractors. These have similar equipment to the single-use welder tractors plus additional attachments. The welder/ pipelayer Challenger combo tractor has two hydraulic planetary winches while the welder/ loader tractor can support a 416 or a 420 loader with 77 and 88 horsepower respectively.

Welding support equipment sold by Challenger includes:

  • External clamps
  • Pneumatic and manual internal clamps
  • Heat induction system for welding preparation
  • Pipe-facing machines to secure pipes for beveling
  • Saddle and band-type cutting and beveling machines

Pipe trailers and lifters

The Challenger CH65 and CH75 pipe carriers come equipped with a Hiab 250 knuckleboom crane and are available for rent at a monthly rate of $9,500. The Challenger PC30 pipe carrier is designed specifically for the Caterpillar Challenger Series tractor. It offers removable racks, cradles sized for each pipe diameter and the option for a knuckleboom crane behind the cab so it is self loading and unloading.

Challenger pipe trailers handle well in mud, dirt, sand and snow and have 4in strap winches along the length of the trailer to keep the load from shifting. They can handle general cargo and single or double-joint pipes. Quick-adjustable saddle width with slide control and chain lock means they can be used for varying pipe diameters. Models with rubber tracks have great flotation and stability and maximum speeds of 30mph.

Challenger stocks the Vaculift RC40D plant pipe lifter and the RC10 to RC20 pipe lifters for track vehicles. Pipe lifters are much more efficient than pipe hooks, pipe forks or pipe tongs. They decrease damage to the pipe, reduce the need for men on the ground and improve safety. Pipe lifters therefore reduce overall costs compared to other methods. The model number of the pipe lifter corresponds to 1,000kg of capacity.

Challenger also stocks pipe support equipment including:

  • Challenger roli cradles
  • Lined steel choker belts
  • Lowering-in belts
  • Choker slings
  • Pipe hooks and inserts

Test pumps

Challenger’s range of combined pumps to fill and pressurise pipelines includes the FT-86, FT-83, FT-835 and the FT-535. The fill rate ranges from 500 gallons per minute (GPM) at 231 feet of head for the FT-535 to 2,200 GPM at 270 feet of head for the FT-83. The test performance ranges from 8.4 GPM at 10,000 pounds per square inch (PSI) with a 0.75in plunger for the FT-86 to 93 GPM at 1,000 PSI with a 2.5in plunger for the FT-83. Challenger speciality test pumps offer a test performance as high as 165 GPM at 2,950 PSI with a 2.5in plunger for the T-31 model.

Pipe benders

Challenger pipe benders are designed to bend steel pipes of various thicknesses and alloys, for pipe diameters from 6in up to 60in depending on the model. Hydraulic controls allow a single operator complete control of all bending machine functions. Bending sets are required for each pipe size within the machine range. These are also supplied by Challenger.

White Papers

  • Pipeline Equipment Rental Rates

    This white paper features rental rates of various equipment supplied by Challenger Services, including pipelayers, clamps and pipe benders.
