Destec Engineering Pipe Clamp Connectors and On-Site Machining Services
Destec Engineering specialises in high-pressure containment and on-site machining products and services for the offshore sector and a variety of other industries.
The company has a comprehensive selection of in-house designed and manufactured portable installation and servicing equipment that performs a wide range of on-site machine shop operations worldwide.
Clamp connectors for piping operations in the offshore industry
Destec’s fire-tested, type-approved G-Range clamp connector is used extensively in activities / processes such as production manifold, flow line and valve installations.
Weighing 75% less than an ANSI flange, the G-Range design features only four bolts per joint, resulting in an easy and cost-effective assembly. It is the recognised standard for clamp connectors by the oil and gas industry.
Supplied as standard with an all-metal seal ring, the G-Range connector is designed primarily for adverse pressure, temperature and thermal shock conditions, and is in-line with Destec’s quality and reliability standards.
Many different types of connector are available, such as butt weld and blind hubs, elbows, nozzles, enlarging and reducing hubs, and orifice metering connections.
Specialised connectors such as hinged closures for pressure vessels are also available.
Destec G-Range clamp connector hubs can be made with carbon, stainless, alloy and duplex steels, with compatible clamp and seal ring materials.
Single-bolt subsea connectors
The Destec GSB single-bolt clamp set is a purpose-designed unit for operations in which a conventional four-bolt G-Range clamp series would be impractical.
The GSB Clampsets are supplied with a mounting plate to accommodate necessary guidance / pull-in systems for alignment purposes, as well as stab connectors for hydraulic and electrical circuits.
A client’s specific sealing requirements or standard G-Range type hubs with metal-to-metal seal rings can be incorporated, in addition to larger clamp sizes and special designs (dual / multi / concentric bore).
A number of GSB clamps have been supplied with fabricated spool pieces for mating to flexible risers.
The GSB Clampsets are available with a blend of molykote and epoxy resin coatings with subsea applications.
Onsite leak sealing and machining services
Destec Engineering supplies specialised precision on-site machining and leak sealing services.
Ranging from small maintenance projects to large-scale plant shutdowns, the company’s services enhance the efficiency of its clients’ facilities, reduce costs and downtime, as well as increasing production while retaining a high level of quality and safety.
Destec operates all-year round on a worldwide basis and is able to quickly deploy its products and services to site.
Destec products include:
- Certified bolt tightening and tensioning
- Online leak sealing
- On-site machining
- Overlay welding
- Regenerator and vessel head removal
Destec has a fully equipped machine workshop with a computer numerical control (CNC) turning capacity of up to 1m in diameter, in addition to vertical machining centres and a diverse range of general purpose machines.
Products and Services
Boiler Inspection Caps
Destec's range of boiler inspection caps have been specifically developed to possess all the features commonly required by boiler and pressure plant operators.
Destec door closures have been specially designed to provide quick access to pressure vessels and can be operated safely at speed for optimal efficiency.
G-Range Clamp Connectors
Destec's catalogue of G-range clamp connectors has been meticulously developed to meet the requirements of offshore plant operators.
Offshore Inspection Services
Destec Engineering has amassed a considerable portfolio of metrological and NHE skills through years of involvement in the oil and gas, petrochemical and power generation industries.
Metal-to-Metal Seal Rings
Destec is well regarded as an experienced specialist in the design and manufacture of high pressure and high temperature metal-to-metal static sealing solutions.
Single Bolt Subsea Connectors
Destec's GSB Subsea Single Bolt Connector has been purposefully built for use in operations where the installation of conventional four-bolt G-Range pipe connections would be unfeasible.
High-Pressure Static Seals for Marine Activities
Destec is pleased to present its innovative sealing system, which incorporates a modified cone ring to provide optimal leak tightness under even the severest pressure, temperature, thermal cycling and shock conditions.
Leak-Resistant Pipe Connections
Destec's G-range pipe connection system provides significant advantages over traditional systems, due in part to their efficiency, lightness and reliability, as well as their optimised, leak-resistant design.
Compact Flanges for Offshore Sector Applications
Destec's range of compact flanges feature an economical design, which allows for a reduction in the component's weight when compared with standard ANSI flanges, while maintaining a robust and high-integrity joint.
Global 24-Hour Support Services for Offshore Operations
As a leading supplier of offshore service solutions, Destec possesses a versatile array of tools and machinery that has been designed and manufactured in-house for optimal accuracy and efficiency.
Regenerator and Reactor Vessel Head Removal for Offshore Sites
Destec Engineering is a specialist provider of industry-approved solutions for the oil and gas sector.
