MSA Fixed Gas and Flame Detection
At MSA, our business is safety. We’ve been the world’s leading manufacturer of high-quality safety products since 1914, providing sophisticated devices and protective gear – the result of countless R&D hours, relentless testing, and an unwavering commitment to quality that saves lives and protects thousands of men and women each day.
Our core product focus emphasizes fixed gas and flame detection instruments, industrial head, eye, face, hearing and communications protection, respiratory protective equipment, fall protection products, and portable gas detection instruments and sensors.
As the world leader in fixed gas and flame detection, MSA provides safety solutions that protect workers’ lives. Whether your field is upstream, midstream or downstream, MSA can help you safely navigate with our extensive line of detectors, built to meet your flame, oxygen, combustible and toxic gas detection needs.
Fixed gas and flame detection solutions
MSA offers a wide variety of fixed gas monitoring solutions to detect gas and flame hazards, combustible gases, toxic gases and oxygen deficiency / enrichment. Our instruments reflect the latest developments in sensor and instrumentation design using electrochemical, catalytic bead, metal oxide, photoacoustic infrared, advanced acoustic detection and both point and open path infrared sensing technologies.
Our products have been successfully installed in a variety of applications, including oil rigs, production platforms, wellheads, storage vessels, pipelines and compressor stations, to name a few.
Gas monitors for the offshore industry
Ultima® X series gas monitors provide continuous monitoring of combustible and toxic gases (including hydrogen sulfide) and oxygen deficiency. Installation is both simple and flexible. Ultima X series gas monitors are suitable for indoor and outdoor applications in virtually any type of industry, including offshore refineries, chemical and petrochemical facilities, steel mills, water and wastewater plants, mining, and general industry.
The monitors are engineered using microprocessor-based technology and designed for varied gas-detection needs. Ultima XIR and XI gas monitors offer DuraSource technology, a new and improved light source providing extended sensor life.
Other features and benefits of the Ultima X series include:
- Patented disconnect under power feature
- One board design for easy maintenance
- HART output option
- SIL 2 safety integrity level available for integration into safety systems
Gassonic Observer-i ultrasonic gas leak detector
The new GASSONIC OBSERVER-i ultrasonic gas leak detector incorporates artificial neural network (ANN) technology into the detector’s ‘brain’ and distinguishes real gas leaks from nuisance alarms without requiring any in-field training. Potentially catastrophic gas leaks can be detected instantaneously without gas having to come into contact with a sensing
element. It simply ‘hears’ the leak.
The detector offers ease of use, and does not require in-field training. Ultrasonic gas leak detectors are used in pressurised gas applications to complement conventional gas detection methods. With the unique ultrasonic sensing technology found in all GASSONIC products, the sound of leaking gas is the key to detection.
The detector also provides failsafe operation. Senssonic™ self-test technology checks the device’s electrical integrity and microphone every 15 minutes and ensures the GASSONIC OBSERVER-i detector is operational at all times. Both the microphone and the microphone windscreen are constantly monitored to ensure that the detector always has optimal sensitivity and detection coverage.
Multi-spectral infrared flame detector
MSA’s FlameGard® 5 multi-spectral infrared (MSIR) flame detector with neural network technology (NNT) sets a new industry standard for performance, reliability and value. This is the industry’s first MSIR / NNT flame detector designed to operate at a longer range with a wider field of view and at a higher level of accuracy for superior false alarm immunity.
Additional members of the FlameGard 5 flame detector family include the FlameGard 5 UV / IR detector and the FlameGard 5 UV / IR-hydrogen detector. Both use ultraviolet and infrared detection technology to provide high immunity to false alarms. The FlameGard 5 test lamp for testing FlameGard 5 detectors is the final component in the series.
Important features of the FlameGard 5 Series include:
- A multi-spectral infrared sensing array (in the FlameGard 5 MSIR detector) with highly intelligent neural network processors provides high accuracy through superior false alarm immunity
- Wide field of view
- SIL 3 suitable products
- Continuous optical path monitoring (COPM) checks optical path integrity and electronic circuitry once a minute
- Fire and gas detection system for the offshore industry
The MODEL 10K™ fire and gas detection system from MSA represents the next generation in highly intelligent monitoring solutions designed to help customers reduce hazard vulnerability and meet the world’s most demanding safety standards. The MODEL 10K system is an innovative, modular, Factory Mutual (FM)-approved system that is highly scalable.
Offering intelligence, flexibility and reliability, the system’s controller hardware configuration and software have been tested by Factory Mutual to verify NFPA 72 compliance.
Highlights of the MODEL 10K fire and gas system include:
- Remote I/O capability
- Optional fiber-optic communications
- Color touch screen operator interface
- Supports third party device integration
- Simple, reliable and cost-effective field wiring topology
Open path IR gas detector
The Ultima OPIR-5 detector is an open path IR gas detector that provides continuous monitoring of combustible gas concentrations at a path length of up to 150m. It features a dual detection range (ppm meter and LEL meter), enabling sensitivity to both small and large gas leaks. It is performance approved for use in harsh environments.
Highlights of the Ultima OPIR-5 detector include:
- Capable of detecting methane, natural gas, propane, LPG and other hydrocarbons
- Unitised display for ease of operation and reduced cost
- Automatic gain control compensates for dirty optics, rain and fog
- Multiple communication outputs (HART, ModBus, AMS support) provide complete status and control capability in the control room
Products and Services
FlameGard® Series of Flame Detectors
GasGard® 100 Control System
Gassonic Observer-i Ultrasonic Gas Leak Detector
Model 10K Fire and Gas Detection System
PrimaX IR Gas Transmitter
Every feature of the PrimaX IR Gas Transmitter is designed with reliability in mind to withstand the most challenging environmental conditions throughout the product's life.
Trigard Gas Monitoring System
Ultima® Gas Monitor
Ultima OPIR-5 Open Path Detector
Z-Gard S and DS Sensors
The Z-Gard S Sensor is designed to detect the presence of carbon monoxide, nitrogen dioxide and combustible gases in air.
MSA Gas Detection: Thermal Conditioning for Extracted Gas Samples
Gas detectors are sensitive devices that can be affected by environmental conditions. There are times when a gas sample to be analyzed exists within a hostile environment, with temperatures that are too extreme for direct sensor placement.
MSA Gas Detection
When using a photoacoustic infrared instrument, a gas sample is introduced into the monitor's measurement chamber and the sample is exposed to a specific wavelength of infrared light.
LNG Fueling Stations
Public and private fleet vehicles continue to migrate to use of liquefied natural gas (LNG) and compressed natural gas (CNG) as this cleaner-burning fuel also offers lower fuel costs and lower emissions.
Global safety equipment manufacturer MSA has unveiled a new state-of-the-art safety-training centre at the Regional Learning Alliance (RLA) in Cranberry Township, Pennsylvania, US.Read more
MSA's ALTAIR 5X Multi-gas detector for simultaneous detection of up to six gases offers a new photoionisation (PID) sensor option.Read more
The US's drive to remove its dependence on foreign energy sources significantly relies upon a safe and affordable conversion to natural gas.Read more
MSA's Custom Products group offers individually designed solutions for customer monitoring, control and data acquisition applications. Our design flexibility allows our custom products to meet virtually any gas monitoring need, as each custom system is individually designed to provide the very best solution for unique applications.Read more
The GasGard 100 Control System, a scalable, high-performance data acquisition / logging platform, is now available with a 10.4in TFT VGA LED Panel PC with resistive touchscreen display providing intuitive and smart operator control.Read more
MSA's SIL 2-certified PrimaX IR Combustible Gas Monitor withstands the most challenging environmental conditions.Read more
The Chemgard photoacoustic infrared (IR) gas monitor with IR sensing technology provides precise, low-cost, high-performance monitoring for one hundred different industrial gases.Read more
Why monitor refrigerants?Read more
MSA, the Safety Company, now offers next-day shipping on key varieties of Ultima® X detectors and replacement sensors, FlameGard® flame detectors and Chillgard® monitors.Read more
MSA, the Safety Company, has unveiled its recently renovated testing facility for fixed gas and flame detection (FGFD) products.Read more
MSA has introduced the Altair 2X line of gas detectors that incorporate industry leading XCell® sensor technology to deliver unparalleled performance while drastically minimising total cost of ownership, increasing durability and delivering enhanced worker safety, compliance and traceability.Read more
Leading protective helmet manufacturer MSA has introduced the Fas-Trac® III ratchet suspension to improve comfort, retention and stability.Read more
Designed with artificial neural network (ANN) intelligence and real-time broadband acoustic sound processing technology, the state-of-the-art Gassonic Observer-i ultrasonic gas leak detector sets a new global industry standard in highly reliable ultrasonic gas leak detection with unprecedented suppression of false alarms.Read more
“When You Go In, We Go In With You” – MSA Launches New Marketing Campaign to Connect with Firefighters
Fighting fires is not for the faint of heart. But for those who answer the call, they become part of a family known for its selflessness, bravery and commitment to leaving no person behind. That's exactly the message global safety equipment manufacturer MSA intends to convey through a new marketing campaign created to recognize the spirit of camaraderie and commitment that exists among firefighters around the world.Read more
MSA has released a gree white paper on Offshore Technology.Read more
The modularity of the SUPREMATouch modular fire and gas detection system enables a variety of fire and gas detection configurations that meet the requirements of virtually any offshore application, including redundant systems with up to a SIL 3 rating.Read more
Featuring HART field communications protocol for improved asset management, Ultima X gas monitors continuously monitor numerous hazards using catalytic, electrochemical, and infrared detection methods.Read more
The Ultima OPIR-5 detector features a single detection beam for improved accuracy and reduced drift.Read more
The MODEL 10K fire and gas detection system is FM-approved to NFPA compliance.Read more
For maximum durability, the FlameGard5 MSIR flame detector is housed in a 316 stainless-steel explosion-proof enclosure, making it ideal for use in offshore applications such as drilling and production platforms, and LNG/LPG processing and storage facilities.Read more
HART and ModBus communication options for the UltraSonic EX-5 gas leak detector provide complete status and control capability in the control room.Read more
The UltraSonic EX-5 Gas Leak Detector from MSA detects airborne leaks from high-pressure gas systems.Read more
